CRS NI Trommel 1620
Price excl. GST
POA
Print
INFO
Type of Product Group
Waste sorting equipment
Brand / model
CRS NI Trommel 1620
Year of Production
2019
Hours of operation
3,100 h
Location
Llangyfelach
Country
United Kingdom
Mascus ID
F535BDF0
ITEM DETAILS
Internal stock no.
SH2023/06
Extra information
Comprising of following:
Feed Hopper
1400 mm wide steel slatted conveyor with Nord 3 kw Electric motor drive.
Twin dosing drums 5.5kw Electric motor drive each.
Dimensions: 11 m long x 3 m wide x 4.5 m high.
Trommel Feed Conveyor
15.5 m long x 1200 mm wide belt. Nord 7.5 kw Electric motor drive.
Conveyor Tek 1200 mm wide Overband Magnet with 1.5Kw Electric motor drive.
Trommel Screen 1620
Comprising of two drums linked together total length of 19.4 m, diameter 2 m.
Drum No1: Fitted with 15 mm square punch plates.
Driven by all 4 wheels 5.5kw Electric motor drive each.
Drum No2: Fitted with 15 mm & 25 mm square punch plates.
Driven by 2 wheels on discharge end only 5.5kw Electric motor drive each.
Mounted on supporting structure complete with including access platform & stairs.
Dimensions: 2.7 m wide x 2.9 m high.
Reject Out feed Conveyor.
8.5 m long x 1200 mm wide belt. Nord 5.5 kw Electric motor drive.
Air Vacuum system over conveyor belt with 18.5 kw Electric motor drive fan unit.
Electrical control panel
The system is still currently operating price excludes dismantling and removal from site
Recycling Plant & Machinery
Bryntywood SA5 7LP Llangyfelach Swansea United Kingdom
