SAKAI SW884ND

Price excl. GST

POA

Compnay LOGO
Images12
Sakai SW884ND Single drum rollers
Sakai SW884ND Single drum rollers
Sakai SW884ND Single drum rollers
FavoriteFavorite
shareShare
Save searchSave search
Print

INFO

Type of Product Group
Single drum rollers
Brand / model
SAKAI SW884ND
Year of Production
2023
Hours of operation
53 h
Location
Forest Lake, Minnesota
Country
United States
Mascus ID
C16694EB

ITEM DETAILS

Internal stock no.
C005753
Manufacturing / Serial number
3SW79-40348
Power Output
95.6 kW (130 hp)
Extra information
Description: Features & Benefits: 3,000 VPM – 10 IPF ... 4.55 MPH Several amplitude and frequency settings/combinations per drum at operator’s station Counter-rotating eccentric weights All vibration controls at instrumental panel Chamfered drum edges 180 seat rotation Heavy-duty hitch design Durable rubber isolator system for vibratory drums Independent drum vibration Great side and curb clearance Triple filtered spray system Dual drum hydrostatic drive Increased drum wear-resistance thanks to alloy with 20% increase in hardness Standard Safety Equipment ROPS Sakai proprietary emergency brake pedal which kills the engine and stops the machine instantly. 3 inch retractable seat belt 39 inches of visibility to the front and rear from the operators seat Low profile design for low center of gravity Operator deck guard rails Horn and backup alarm Electric parking brake w/ interlock Specifications DRUM Size (w x d) 79 X 55 ins | 2000 X 1370 mm OPERATING Weight 29,165 lbs | 13,230 kg OSCILLATION Frequency 2,800 vpm | 46.7 Hz Centrifugal Force 38,600 lbs | 172 kN Normal Amplitude 0.024″ | 0.60 mm VIBRATION Frequency 3,000 vpm | 50 Hz Centrifugal Force 35,585 lbs | 158 kN Nominal Amplitude 0.022 ” | 0.55 mm ENGINE Make & Model Cummins QSF 3.8 T4 Final Horsepower 130 HP | 97.0 kw ... 2,200 rpm BRAKING Systems Hydrostatic Service Brake + SAHR Parking Brake + Combined Footbrake OPTIONS Airconditioning: 0 Enginemake: CUMMINS Enginemodel: QSF3.8 Gps: 0 Heater: 0 Ropstype: Enclosed Basedrivespeed: 4.55 Enginerebuilt: 0 Articulating: 1 Transmissionrebuilt: 0Show more

American State Equipment - Milwaukee

2055 South 100th Street 53227 Milwaukee Wisconsin United States
