BIK RC-31TJ
Price excl. GST
POA
7
Favorite
Share
Save searchPrint
INFO
Type of Product Group
Other Cranes
Brand / model
BIK RC-31TJ
Condition
New/unused
Location
Milford, Massachusetts
Country
United States
General grade
1
2
3
4
5
Mascus ID
8862C300
ITEM DETAILS
Maximum lift capacity
31,000 ton
Maximum lift height
1.22 m
Extra information
Boom Details
New – BIK Roofing-Crane Series RC-31-TJ – 31 ton/m Knuckle Boom with Jib – by PM
Folding Hydraulic 4 extn Knuckle Boom with Detachable 3 extn jib – 66’ Horizontal reach – 78’ Vertical Reach
Main Boom Horizontal Capacity:
12,300 lb ... 14’
8,600 lb ... 20’
6,300 lb ... 27’
5,000 lb ... 33’
4,000 lb ... 40’
Main w/Jib Horizontal Capacity:
2,000 lb ... 50’
1,670 lb ... 55’
1,500 lb ... 60.5’
1,340 lb ... 66’
Jib Capacity in “Cobra” Position:
42’ up / 40’ out – 3,240 lbs
42’ up / 45’ out – 2,500 lbs
42’ up / 55’ out – 2,140 lbs
55’ up / 12’ out – 6,400 lbs
55’ up / 20’ out – 3,850 lbs
55’ up / 30’ out – 2,360 lbs
PM “Power-Link”
connecting rods at First Boom and Knuckle, Double pilot operated on slewing and pilot check valves on all cylinders
Planetary Gear Rotation Motor & Continuous Boom Rotation
– for maximized slewing torque and reliability
15 Degree negative angle
on main boom, 20 degree negative jib angle
– Hyd Extra Wide Main outriggers
at base – 5’ total span
Two Hydraulic Oil Coolers
, high pressure return filter and hydraulic oil tank on boom
One Extra Hyd Functions
pkumbed to end of jib for possible hydraulic hook rotator device
Painted PM Blue
– load chart on boom in FT. & LBS. – All OSHA required safety decals
Warranty: 1-Yr. part & labour on entire boom, 3-Yr. on Structural Components –
Engineer Stability, load tested and certified
Installation –
install new boom as described above, back of cab (or at rear)
with New PTO and New Hyd pump, fresh hyd oil.
Deck Details
New –
22’ long x 102” Dec
k
Installed on Truck
Pockets/rub rails
54” of main sill overhang for the Sub-Frame of Knuckle Boom
Steel Checker plate Deck surface
48” Headboard
Reverse Rail sliding track on the driver’s side
12 winches and straps (30’) with required Conspicuity and Reflectors
Forks storage bracket at rear
All steel painted Gloss Black.
Truck Details
New
– Freightliner 108SD 3-Axle Diesel Truck:
60,000 lb GVWR
Truck cab white
9L Cummins Diesel
380 hp
Allison 3000 Series Auto Trans
.
20,000 lb fronts with 425/65R22.5 Front Floatation tires on Alum rims
40,000 LB Rears on Tuftrac Suspension with 11R22.5 tires on Aluminum rims
Double frame chassis
Truck Features Include: Two Stage Engine Brake, Air Cond., AM/FM stereo w/bluetooth, cruise, tilt/tele steer column, power windows/locks, chrome bumper and grill, power and heated mirrors, block heater, two man pass seat, painted ext visor, trailer air tow package, rear wheel lock ups, 80 gal alum fuel tank, etc…
Other Options at Extra Cost:
(2) pcs – PVC stabilizer pads with holders at rear
(1) pc – 36” aluminum Storage Boxes installed
1” drawplate installed at rear with heavy-duty pintle hook and trailer hook-ups
Hydraulic Hook rotator w/hook (ability to rotate hook/pallet forks from boom remote
Self-Levelling Pallet Forks with Height Adjustment
13,000 lb self-steer lift axle installed ahead of t/a with 22.5” Alum Rims & low profile tires
Alternate Truck Chassis:
New 2025 F-Liner 114SD
– 12L Diesel 470 hp, Automated Trans, 20F/46R – 66k GVWR, Loaded w/Options
New 2025 Western Star 47X 4-axle
, 500 hp Diesel, Automated Trans (same specs as above)
New 2025 Kenworth T880 4-axle
, 510 hp Diesel, Automated Trans (same specs as above)
