CAT 323 D

Price excl. GST

Compnay LOGO
Images8
CAT 323 D Crawler excavators
CAT 323 D Crawler excavators
CAT 323 D Crawler excavators
FavoriteFavorite
shareShare
Save searchSave search
Print

INFO

Type of Product Group
Crawler excavators
Brand / model
CAT 323 D
Year of Production
2023
Hours of operation
800 h
Country
China
General grade
1
2
3
4
5
Mascus ID
26AECB69

PRICE

Currency selection

ITEM DETAILS

Internal stock no.
1
Power type
Diesel
Manufacturing / Serial number
1
Amount of previous owners
1
Last Inspection Time
2025-04-22
Undercarriage condition
Good Condition
Engine
Original
Gross Weight
23,100 kg
Power Output
110 kW (150 hp)
Engine manufacturer
Original
Registration number
1
Emission level
Stage V / Tier V
Bucket capacity
1.20 m3
Track width
3,180 mm
Output of the auxiliary hydraulics
205 l/min
Transport dimensions (LxWxH)
9460 x 3180 x 3050 mm
Original colour
Original
Dipper / stick length
2,900 mm
Condition info/guarantee
1 Year
Production country
United States
Delivery terms
FCA, FOB, CFR, CIF, EXW
Certificates
EPA, CE
Attachments
We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours,24 hours, holidays and Sundays Address: Shanghai City, China Contact: Jason Whatsapp: +86 13675656717 Mobile:+86 13675656717 Wechat:13675656717 Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs.
Accessories
Air conditioning
Additional hydraulics
Skeleton bucket
Engine heater
Show more
Extra information
规格 动力传统动力 厂商合资/进口 铲斗反铲 吨位(吨)23 整机工作重量(kg)22300-23100 铲斗容量(m³)1.2 动臂长度(mm)5700 斗杆长度(mm)2900 原产地日本 性能 回转速度(rpm)11.5 行走速度(km/h)3.5/5.7 爬坡能力(%)70/35° 铲斗挖掘力(kN)140 斗杆挖掘力(kN)106 动力系统 发动机型号C6.4ACERT 额定功率(kw/rpm)110/2000 排量(L)6.4 气缸数(个)6 缸径×行程(mm)102×130 冷却方式水冷 液压系统 主泵最大流量(l/min)205 先导油路(MPa)3.9 工作液压油路(Mpa)3.5 行走液压回路(Mpa)3.5 回转液压回路(Mpa )2.5 主溢流设定压力(Mpa)3.5 动臂油缸-个数×缸径×行程(mm)120×1260 斗杆油缸-个数×缸径×行程(mm)140×1504 铲斗油缸-个数×缸径×行程(mm)120×1104 液压破碎管路是否标配否 油类容量 燃油箱(L)410 液压油箱(L)120 液压系统(L)260(包括油箱) 发动机油更换量(L)30 冷却液(L )25 主体尺寸 运输总长度(mm)9460 运输总宽度(mm)3180 运输总高度(mm)3050 驾驶室全高(mm)2950 履带接地长度(mm)3650 履带总长度(mm)4455 履带板宽度(mm)600 履带总宽度(mm)3180 履带轨距(mm)2380 最小离地间隙(mm )450 配重离地间隙(mm)1020 后端回转半径(mm )2940 作业范围 停机面最大挖掘半径(mm)9850 最大挖掘深度(mm)6710 最大挖掘高度(mm)9470 最大卸载高度(mm)6500 最大垂直挖掘深度(mm)5860 最大有效挖掘深度(mm)6380 推土板宽度×高度(mm)无推土铲 推土铲举升或推深(mm)无推土铲Show more

上海吉潘贸易有限公司

上海市松江区车墩镇莘莘路32号3799 201600 上海 上海 China
